Introduction

Flotation, in mineral processing, method used to separate and concentrate ores by altering their surfaces to a hydrophobic or hydrophilic condition—that is, the surfaces are either repelled or attracted by water.

Froth flotation can selectively separate core minerals from middlings or tailings, making them high-grade mineral concentrate. Since froth flotation can separate minerals from already processed concentrates besides the primary ore, it is considered to have high efficiency in recovering minerals.

request a quote e-mail

Working principle

In the flotation cell, the slurry after the addition of the chemical treatment is stirred and aerated, so that some of the ore particles are selectively fixed on the bubbles and the surface of the slurry is scraped to form a foam product, with the other part left in the slurry, which achieves the purpose of separating minerals.

Advantages

  • The unmanned automatic control system has the functions of suction and flotation and does not require any auxiliary equipment.

  • The effective flotation volume of one tank is increased; the output is increased; the work efficiency is improved, and various rough selection, sweeping, and selection operation modes are satisfied.

  • The degree of foam refinement is high, and the accuracy of flotation is increased by 3-5%.

  • Compared with conventional machines, it can save 1/3~1/2 of electric power and has lower operating costs.

CUSTOMER CASE OF FTM

  •
	  Flotation Separation Line

    Flotation Separation Line

  •
	  Gold Ore Processing Plant in Zimbabwe

    Gold Ore Processing Plant in Zimbabwe

  •
	  Copper-Molybdenum Ore Beneficiation Plant in Mongolia

    Copper-Molybdenum Ore Beneficiation Plant in Mongolia

Technical Specifications

Category Model Effective Volume
(m³)
Processing capacity Main shaft Loam board Dimensions
(LxWxH)
(M)
Power
(kw)
Rotate speed
(r/min)
Rotate speed
(r/min)
Power
(kw)
XJK type flotation machine XJK-0.35 0.35 0.18-0.4 1.5 483 25 1.1 0.7×0.7×0.7
XJK-0.62 0.62 0.3-0.9 3 400 25 1.1 0.9×0.82×0.85
XJK-1.1 1.1 0.6-1.6 5.5 330 25 1.1 1.1×1.1×10
XJK-2.8 2.8 1.5-3.5 11 280 25 1.1 1.75×1.6×1.1
XJK-5.8 5.8 5-7 22 240 25 1.5 2.2×2.2×12
SF type flotation machine SF-0.37 0.37 0.2-0.4 1.5 386 25 1.1 0.7×0.7×0.75
SF-0.7 0.7 0.3-0.9 3 400 25 1.1 0.9×0.82×0.95
SF-1.2 1.2 0.6-1.6 5.5 330 25 1.1 1.1×1.1×1.1
SF-2.8 2.8 1.5-3.5 11 268 25 1.1 1.75×1.6×1.15
SF-4 4 2-4 15 220 25 1.5 1.85×2.05×12
SF-8 8 4-8 30 191 25 1.5 2.2×2.9×1.4
SF-10 10 5-10 30 191 25 1.5 2.2×2.9×1.7
SF-20 20 5-20 30×2 191 25 1.5 2.85×3.8×2.0
JJF type flotation machine JJF-2 2 1-3 7.5 443 25 1.5 1.4×1.4×1.1
JJF-4 4 2-4 11 305 25 1.5 1.6×2.15×1.25
JJF-8 8 4-8 22 233 25 1.5 2.2×2.9×1.4
JJF-10 10 5-10 22 233 25 1.5 2.2×2.9×1.7
JJF-16 16 5-16 30 180 25 1.5 2.85×3.8×1.7
JJF-20 20 5-20 37 180 25 1.5 2.9×3.8×20

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.

Model Effective Volume
(m³)
Processing capacity
XJK-0.35 0.35 0.18-0.4
XJK-0.62 0.62 0.3-0.9
XJK-1.1 1.1 0.6-1.6
XJK-2.8 2.8 1.5-3.5
XJK-5.8 5.8 5-7
SF-0.37 0.37 0.2-0.4
SF-0.7 0.7 0.3-0.9
SF-1.2 1.2 0.6-1.6
SF-2.8 2.8 1.5-3.5
SF-4 4 2-4
SF-8 8 4-8
SF-10 10 5-10
SF-20 20 5-20
JJF-2 2 1-3
JJF-4 4 2-4
JJF-8 8 4-8
JJF-10 10 5-10
JJF-16 16 5-16
JJF-20 20 5-20

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
