Introduction

PCX type heavy hammer crusher is widely used in many industries such as mining, smelting, building materials, highway, rail-way, water conservancy and chemical industry. It is suitable for crushing various medium hardness and brittle materials with compressive strength less than 150Mpa, such as limestone, bluestone, coal gangue, etc.

request a quote e-mail

Advantages

  • Big crushing ratio, short flow process, less land occupation, less equipment, Easy maintenance;

  • PCZ Heavy hammer crushers,shape up by single crushing without second time, to reduce the cost by around 40%, which ensure energy and investment saving.

Technical Specifications

Model Rotor diameter×Length(mm) Feed Opening Length×Width(mm) Feeding Size(mm) Processing Capacity(t/h) Power(kw) Dimensions(L×W×H)(mm)
PCX 0706 700×570 618×510 ≤150 30-70 75 1950×1340×1480
PCX 0808 800×750 780×610 ≤150 45-100 132 2280×1790×1570
PCX 0910 900×1000 1070×750 ≤200 70-200 2×110 2600×2200×1940
PCX 1012 1000×1180 1315×900 ≤200 130-300 2×132 2760×2430×2290
PCX 1213 1260×1280 1430×1010 ≤250 200-350 2×160 3067×2622×2580
PCX 1216 1260×1490 1630×1010 ≤250 230-500 2×200 3067×2832×2580
PCX 1220 1260×1950 2090×1010 ≤250 300-700 2×220 3067×3380×2580
PCX 1622 1600×2150 2300×950 ≤300 400-1200 2×315 4120×3680×3200

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.

Model Feeding Size(mm) Processing Capacity(t/h)
PCX 0706 ≤150 30-70
PCX 0808 ≤150 45-100
PCX 0910 ≤200 70-200
PCX 1012 ≤200 130-300
PCX 1213 ≤250 200-350
PCX 1216 ≤250 230-500
PCX 1220 ≤250 300-700
PCX 1622 ≤300 400-1200

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
